AVENTICS 二位三通換向閥5792500220

規格

操作電子

額定流量Qn520 l/min

換向原理3/2

結構NC

壓縮空氣 接口 出口? 6x1

最小運行壓力2 bar

最大運行壓力8 bar

工作電壓DC24 V

電壓偏差 DC-10% / +10%

手動控制裝置鎖定式

電氣連接 類型多芯插頭

電氣連接 尺寸ISO 15217, C 型

密封原理軟密封

先導內部

閥門結構形式提動閥

連接類型管式連接

復位裝置帶彈簧復位

組合原理?（閉鎖原理）終端閥門

可以組裝成塊可以組裝成塊

最低環境溫度-15 °C

最高環境溫度50 °C

介質溫度最小值-15 °C

介質溫度最大值50 °C

介質壓縮空氣

顆粒大小 max.5 μm

5792180220 V579-3/2NC-DA04-024DC-1,2-RV4-MODI

5792200210 V579-3/2NC-DA06-012DC-1,2-RV4

5792200220 V579-3/2NC-DA06-024DC-1,2-RV4

5792200620 V579-3/2NC-DA06-024DC-1,2-RV4-LED

5792205220 V579-3/2NC-DA06-024AC-1,2-RV4

5792205270 V579-3/2NC-DA06-110AC-1,2-RV4

5792205280 V579-3/2NC-DA06-230AC-1,2-RV4

5792205680 V579-3/2NC-DA06-230AC-1,2-RV4-LED

5792280220 V579-3/2NC-DA06-024DC-1,2-RV4-MODI

5792500210 V579-3/2NC-DA06-012DC-04-RV4

5792500220 V579-3/2NC-DA06-024DC-04-RV4

5792500310 V579-3/2NC-D014-012DC-04-RV4-USA

5792500320 V579-3/2NC-D014-024DC-04-RV4-USA

5792500620 V579-3/2NC-DA06-024DC-04-RV4-LED

5792505220 V579-3/2NC-DA06-024AC-04-RV4

5792505270 V579-3/2NC-DA06-110AC-04-RV4

5792505280 V579-3/2NC-DA06-230AC-04-RV4

5792505370 V579-3/2NC-D014-110AC-04-RV4-USA

5792505680 V579-3/2NC-DA06-230AC-04-RV4-LED

5792510210 V579-3/2NO-DA06-012DC-04-RV4

5792510220 V579-3/2NO-DA06-024DC-04-RV4

5792510310 V579-3/2NO-D014-012DC-04-RV4-USA

5792510620 V579-3/2NO-DA06-024DC-04-RV4-LED

5792515220 V579-3/2NO-DA06-024AC-04-RV4

5792515270 V579-3/2NO-DA06-110AC-04-RV4

5792515280 V579-3/2NO-DA06-230AC-04-RV4

5792515680 V579-3/2NO-DA06-230AC-04-RV4-LED

5792520210 V579-3/2NO-DA06-012DC-04-RV4-EXT

5792520220 V579-3/2NO-DA06-024DC-04-RV4-EXT

5792520620 V579-3/2NO-DA06-024DC-04-RV4-EXT-LED

5792525220 V579-3/2NO-DA06-024AC-04-RV4-EXT

5792525270 V579-3/2NO-DA06-110AC-04-RV4-EXT

5792525280 V579-3/2NO-DA06-230AC-04-RV4-EXT

5792525680 V579-3/2NO-DA06-230AC-04-RV4-EXT-LED

5792570210 V579-3/2NC-DA06-012DC-04-RV4-EXT

5792570220 V579-3/2NC-DA06-024DC-04-RV4-EXT

5792570620 V579-3/2NC-DA06-024DC-04-RV4-EXT-LED

5792575220 V579-3/2NC-DA06-024AC-04-RV4-EXT

5792575270 V579-3/2NC-DA06-110AC-04-RV4-EXT

5792575280 V579-3/2NC-DA06-230AC-04-RV4-EXT

5792575680 V579-3/2NC-DA06-230AC-04-RV4-EXT-LED

5792580220 V579-3/2NC-DA06-024DC-04-RV4-MODI

5792600000 V579-3/2NC-DA08-04-RV4

5792600010 V579-3/2NO-DA08-04-RV4

5792600210 V579-3/2NC-DA08-012DC-04-RV4

5792600220 V579-3/2NC-DA08-024DC-04-RV4

5792600620 V579-3/2NC-DA08-024DC-04-RV4-LED

5792605220 V579-3/2NC-DA08-024AC-04-RV4

5792605270 V579-3/2NC-DA08-110AC-04-RV4

5792605280 V579-3/2NC-DA08-230AC-04-RV4

5792605680 V579-3/2NC-DA08-230AC-04-RV4-LED

5792610210 V579-3/2NO-DA08-012DC-04-RV4

5792610220 V579-3/2NO-DA08-024DC-04-RV4

5792610620 V579-3/2NO-DA08-024DC-04-RV4-LED

5792615220 V579-3/2NO-DA08-024AC-04-RV4

5792615270 V579-3/2NO-DA08-110AC-04-RV4

5792615280 V579-3/2NO-DA08-230AC-04-RV4

5792615680 V579-3/2NO-DA08-230AC-04-RV4-LED

5792620210 V579-3/2NO-DA08-012DC-04-RV4-EXT

5792620220 V579-3/2NO-DA08-024DC-04-RV4-EXT

5792620620 V579-3/2NO-DA08-024DC-04-RV4-EXT-LED

5792625220 V579-3/2NO-DA08-024AC-04-RV4-EXT

5792625270 V579-3/2NO-DA08-110AC-04-RV4-EXT

5792625280 V579-3/2NO-DA08-230AC-04-RV4-EXT

5792625680 V579-3/2NO-DA08-230AC-04-RV4-EXT-LED

5792670210 V579-3/2NC-DA08-012DC-04-RV4-EXT

5792670220 V579-3/2NC-DA08-024DC-04-RV4-EXT

5792670620 V579-3/2NC-DA08-024DC-04-RV4-EXT-LED

5792675220 V579-3/2NC-DA08-024AC-04-RV4-EXT

5792675270 V579-3/2NC-DA08-110AC-04-RV4-EXT

5792675280 V579-3/2NC-DA08-230AC-04-RV4-EXT

5792675680 V579-3/2NC-DA08-230AC-04-RV4-EXT-LED

5792800210 V579-5/2OC-DA06-012DC-04-RV4

5792800220 V579-5/2OC-DA06-024DC-04-RV4

5792800320 V579-5/2OC-D014-024DC-04-RV4-USA

5792800620 V579-5/2OC-DA06-024DC-04-RV4-LED

5792805220 V579-5/2OC-DA06-024AC-04-RV4

5792805270 V579-5/2OC-DA06-110AC-04-RV4

5792805280 V579-5/2OC-DA06-230AC-04-RV4

5792805680 V579-5/2OC-DA06-230AC-04-RV4-LED

5792870220 V579-5/2OC-DA06-024DC-04-RV4-EXT

5792900210 V579-5/2OC-DA08-012DC-04-RV4

5792900220 V579-5/2OC-DA08-024DC-04-RV4

5792900620 V579-5/2OC-DA08-024DC-04-RV4-LED

5792905220 V579-5/2OC-DA08-024AC-04-RV4

5792905270 V579-5/2OC-DA08-110AC-04-RV4

5792905280 V579-5/2OC-DA08-230AC-04-RV4

5792905680 V579-5/2OC-DA08-230AC-04-RV4-LED
