AVENTICS無桿氣缸 R480141474

R480141474產品描述RTC-DA-040-0600-BV-MBM00S00BLP000P0P0

規格

活塞- ?40 mm

行程600 mm

接口G 1/4

實用原則雙作用式

磁性銷釘帶磁性活塞

引導集成化導桿

版本 無桿氣缸Basic Version

活塞力792 N

確定活塞推力的壓力6,3 bar

緩沖長度20 mm

緩沖能量10 J

緩沖氣動

緩沖可調節的

最大速度5 m/s

最大行程9900 mm

最小運行壓力2 bar

最大運行壓力8 bar

最低環境溫度-10 °C

最高環境溫度60 °C

介質壓縮空氣

壓縮空氣中的含油量 最小.,0 mg/m3

壓縮空氣中的含油量 最大1 mg/m3

顆粒大小 max.5 μm

重量 0 mm行程2.09 kg

重量 +10 mm行程0.044 kg

R480141474 RTC-DA-040-0600-BV-MM00S00BLP000P0P0

R480147829 RTC-DA-040-0600-BV-MM41S00BLPRA3P0P0

R480148971 RTC-DA-040-0600-HD-MM00S00BLP000P0P0

R480149794 RTC-DA-040-0600-CG-MM00S00BLP000P0P0

R480154366 RTC-DA-040-0600-CG-MM00S00BLP000H4H4

R480156019 RTC-DA-040-0600-BV-MMF1S00BLP000P0P0

R480161549 RTC-DA-040-0600-RI-MM00S00BLP000P0P0

R480163109 RTC-DA-040-0600-RI-MMF1S00BLP000P0P0

R480179959 RTC-DA-040-0600-RI-MM40S00BLP000P0P0

R480181767 RTC-DA-040-0600-BV-MM41S00BLP000P0P0

R480182640 RTC-DA-040-0600-BV-MM00S44BLP000P0P0

R480618973 RTC-DA-040-0600-RR-MM00S00BLP000P0P0

R480620163 RTC-DA-040-0600-RI-MMF1S00BLPPA3P0P0

R480639919 RTC-DA-040-0600-HD-MMF1S00BLP000P0P0

R480645047 RTC-DA-040-0600-CG-MM00S00BLP000H3H3

R480658951 RTC-DA-040-0600-BV-IM40S00NLP000P0P0
