AVENTICS R412000379 旋轉緊湊模塊 RCM-12-090-SE-AP-00

規格

直徑12 mm

壓縮空氣連接M5

磁性銷釘帶磁性活塞

旋轉緊湊模塊結構形式帶齒條的雙活塞

Easy2Combine可用

尺寸RCM-12

空氣流通帶有氣控復位

空氣通道的數量的2

理論力矩6 bar

最小旋轉時間0.2 s

每次旋轉的空氣消耗量5.86 cm3

最大允許的軸向軸承負載330 N

最大允許的徑向軸承負載290 N

最大允許的質量轉動慣量0.7 kg cm2

理論力矩0.95 Nm

重復精度0.2 °

緩沖彈性

旋轉角度 min.0 °

旋轉角度 max.90 °

最小運行壓力2.5 bar

最大運行壓力8 bar

最低環境溫度5 °C

最高環境溫度60 °C

介質溫度最小值5 °C

介質溫度最大值60 °C

AVENTICS RCM 系列的旋轉模塊可以執行各種標準化旋轉運動。這些模塊可直接安裝在小型滑塊上，配備了機械抓爪。

R412000357 RCM-06-090-SE-00-00

R412000358 RCM-06-180-SE-00-00

R412000359 RCM-08-090-SE-00-00

R412000360 RCM-08-180-SE-00-00

R412000361 RCM-12-090-SE-00-00

R412000362 RCM-12-180-SE-00-00

R412000363 RCM-16-090-SE-00-00

R412000364 RCM-16-180-SE-00-00

R412000365 RCM-20-090-SE-00-00

R412000366 RCM-20-180-SE-00-00

R412000367 RCM-25-090-SE-00-00

R412000368 RCM-25-180-SE-00-00

R412000369 RCM-12-090-SH-00-00

R412000370 RCM-12-180-SH-00-00

R412000371 RCM-16-090-SH-00-00

R412000372 RCM-16-180-SH-00-00

R412000373 RCM-20-090-SH-00-00

R412000374 RCM-20-180-SH-00-00

R412000375 RCM-25-090-SH-00-00

R412000376 RCM-25-180-SH-00-00

R412000377 RCM-08-090-SE-AP-00

R412000378 RCM-08-180-SE-AP-00

R412000379 RCM-12-090-SE-AP-00

R412000380 RCM-12-180-SE-AP-00

R412000381 RCM-16-090-SE-AP-00

R412000382 RCM-16-180-SE-AP-00

R412000383 RCM-20-090-SE-AP-00

R412000384 RCM-20-180-SE-AP-00

R412000385 RCM-25-090-SE-AP-00

R412000386 RCM-25-180-SE-AP-00

R412000387 RCM-12-090-SH-AP-00

R412000388 RCM-12-180-SH-AP-00

R412000389 RCM-16-090-SH-AP-00

R412000390 RCM-16-180-SH-AP-00

R412000391 RCM-20-090-SH-AP-00

R412000392 RCM-20-180-SH-AP-00

R412000393 RCM-25-090-SH-AP-00

R412000394 RCM-25-180-SH-AP-00

R412000395 RCM-12-180-SE-00-IP

R412000396 RCM-16-180-SE-00-IP

R412000397 RCM-20-180-SE-00-IP

R412000398 RCM-25-180-SE-00-IP

R412000399 RCM-12-180-SH-00-IP

R412000400 RCM-16-180-SH-00-IP

R412000401 RCM-20-180-SH-00-IP

R412000402 RCM-25-180-SH-00-IP

R412000403 RCM-12-180-SE-AP-IP

R412000404 RCM-16-180-SE-AP-IP

R412000405 RCM-20-180-SE-AP-IP

R412000406 RCM-25-180-SE-AP-IP

R412000407 RCM-12-180-SH-AP-IP

R412000408 RCM-16-180-SH-AP-IP

R412000409 RCM-20-180-SH-AP-IP

R412000410 RCM-25-180-SH-AP-IP

R413000348 SEALING DISK RCM-25-180-SH-AP-00
